BXY-I series Drug Stability Test Chamber
  • Product Category: Products Test Chamber
  • product description:The BXY-I series Drug Stability Test Chamber simulates the long-term stable temperature and humidity environment required for drug failure evaluation using scientific and rigorous methods, and is suitable for pharmaceutical companies to conduct accelerated and long-term tests on raw materials and finished drugs.
 [←]  BXS-SI series Extensible Test Chamber
 [→]  BXY-SI series Drug Stability Test Chamber
  • Products Description


    The BXY-I series Drug Stability Test Chamber simulates the long-term stable temperature and humidity environment required for drug failure evaluation using scientific and rigorous methods, and is suitable for pharmaceutical companies to conduct accelerated and long-term tests on raw materials and finished drugs.



    Products Features


    1

    BRIGHT I control system can automatically compensate the value of control parameters according to the change of environment

    2

    Programmable multi-segment parameter setting: 30 segments 99 cycles design

    3

    The controller can store data records for more than 5 years (not stored by SD card), and record equipment events with exact time, and export them by U disk in unchangeable file format for viewing and backup, and trace the data

    4

    The administrator can assign 14 kinds of equipment operation permissions to 5 operators

    5

    Support data and curve online viewing

    6

    The circulating air volume can be adjusted manually according to the sample loading condition

    7

    Rapid recovery of temperature and humidity after opening the door

    8

    Protection function: upper and lower limit over temperature alarm, over temperature shutdown protection, door open alarm, water shortage alarm, sensor fault alarm, overload protection, leakage protection, compressor over temperature protection

    9

    Glass observation inner door design

    10

    Equipped with printer


    Products Technical Parameters


    Model
         		BXY-150I BXY-250I BXY-400I BXY-800I BXY-1000I BXY-1600I
    Volume [L] 150 250 400 800 1000 1600

    Temp. Range

    without

    Humidification [°C]

    		0~70

    Temp. Range with

    Humidification [°C]

    		10~60

    Temp. Resolution

    [°C]

    		0.1

    Temp. Fluctuation

    at 25°C [°C]

    		±0.5

    Temp. Uniformity

    at 25°C [°C]

    		±1 ±1.5 ±2
    Humidity Range [%] 25~95 30~95

    Humidity Fluctuation [%]

    		±3 ±5
    Power [W] 1900 1950 2000 3500 3600 3700

    Timer Range per

    Segment [h]

    		1~9999

    Internal Dimensions

    W×D×H [mm]

    		510×390×760 510×450×1090 600×640×1050 1200×610×1100 1200×760×1100 1400×850×1350

    Housing Dimensions

    W×D×H [mm]

    		650×820×1400 650×880×1724 745×1070×1695 1362×1068×1789 1362×1168×1789 1562×1238×2039
