BXYC-WX series Horizontal Shaker
  • Product Category: Products Shaker / Oscillator
  • product description:The BXYC-WX series Horizontal Shaker is widely used in bacterial culture, fermentation, hybridization, biochemical reactions, enzyme and cell tissue research, all of which require high temperature and oscillation frequency.
  • Products Description


    The BXYC-WX series Horizontal Shaker is widely used in bacterial culture, fermentation, hybridization, biochemical reactions, enzyme and cell tissue research, all of which require high temperature and oscillation frequency.


    Products Features


    1

    Intelligent operating system: Adopting the BRIGHT I intelligent operating system, it can automatically compensate for control parameter values according to environmental changes

    2

    Large screen touch display: 7-inch touchscreen full color operation screen, supporting temperature, humidity, time, speed, cycle, number of segments, alarm information, instrument operation status display, and displaying Gregorian time and real-time parameters

    3

    Ergonomic large screen: The large touch screen is located on a high inclined plane to prevent screen glare from vertical angles. At the same time, the operator can observe current parameters and other screen information from a comfortable perspective

    4

    Multi stage programming design: supports multi stage operating temperature programming settings, with a maximum of 30 999 cycle custom programs set

    5

    Screen backlight protection: can set lock screen, screensaver, unlock password, etc. to prevent misoperation and arbitrary program changes

    6

    Intelligent variable frequency refrigeration: intelligent frost free operation throughout the entire process, automatically balancing the required cooling capacity, greatly reducing energy consumption, and equipped with compressor delayed start, effectively extending the service life of the compressor

    7

    Gregorian calendar appointment function: Set the running time of the Gregorian calendar appointment, and automatically run according to the preset program when the appointment time is reached

    8

    Data management system: supports curve viewing and data viewing. Real time curves, historical curves, and historical data can be searched and viewed by jumping over time periods, making it easy to trace curve data

    9

    Data storage system: Large capacity USB storage system, supporting more than 1 million data records, supporting USB data export, facilitating data management

    10

    Alarm record tracing: The system can record equipment alarm information and the exact time on its own, making it easy to trace and view

    11

    Internal standard lighting, combined with high transparency tempered glass, facilitates users to check the sample cultivation status without opening the door

    12

    The front adopts an integrated high transparency tempered glass, with a bright, clean, and easy to clean integrated design. Without opening it, you can directly observe the internal cultivation situation

    13

    Adopting high-quality compressor units, reducing noise levels by more than 50%, supporting long-term operation

    14

    Adopting high-quality DC brushless motor with motor slow start function, effectively protecting the motor while avoiding liquid splashing out in the shaking bottle during sudden acceleration and rotation

    15

    Support direct viewing of alarm information, with functions such as instant stop when opening the door, power outage recovery, fault self-diagnosis, door delay alarm, and temperature anomaly alarm


    Products Technical Parameters


    Model BXYC-WX3350/2350/1350 BXYC-WX3280/2280/1280 BXYC-WX3200/2200
    Volume [L] 350 280 200
    Temp. Range [°C] RT+5~60/4~60
    Temp. Resolution [°C] 0.1
    Temp. Fluctuation at 37°C [°C] ±0.3
    Temp. Uniformity at 37°C [°C] ±1
    Rotation Rate [rpm] 30~300
    Rotation Accuracy [rpm] ±1
    Vibration Amplitude [mm] Ø26
    Timer Range [h] 0~999
    Number of Trays [pc] 1
    Power Supply [V, Hz] 220, 50/60
    Power [W] 1400/1800/2800 1200/1600/2400 1100/1500
    Internal Dimensions W×D×H [mm] 1035×675×470 1010×590×470 1010×590×310
    Housing Dimensions W×D×H [mm] 1380×800×1010 1350×700×1000 1260×730×850
    Tray Size W×D [mm] 970×605 950×530
